| Product Information | |
| Category | "Decorative Profiles" U-U1 Shaped - Inlays, Trims & Profiles |
| Material | Cold Rolled Stainless Steel |
| Mfg. STD | ASTM A-240 |
| Grades | 304, 304L, 316, 316L, 201, 430 |
| Tolerances | Width/Height: ± 0.5mm, Thickness : ± 0.05mm, Length : ± 3mm, Degree : ± 3° |
| Colour | Ti-Champagne-Gold |
| Surface Finish | Mirror No.8 |
| Process Information | |
| Sheets (Raw Material) |
To make decorative Stainless Steel Ti-Champagne-Gold Mirror No.8 Finish U-U1 Shaped Profiles & Trims, We use high quality Cold Rolled SS sheets from India & neighbouring countries. |
| Polishing | These Sheets are Polished on Sophisticated Polishing Machines to give an excellent Mirror No.8 Surface Finish. |
| Cutting | These sheets are then cut accurately into required strip sizes with the help of semi-automatic, hydraulic sheering machines. |
| Grooving | After cutting, wherever required, the above strips are grooved on the grooving machines to get right angled bends. |
| Bending | Once the strips are grooved, they are bent on the NC hydraulic machine to give the desired profiles & trims. |
| Protective PVC Films |
1st Layer - 50 to 70 µ 2nd Layer - 30 to 50 µ |
| Material Specification | |||
| Colour | Surface Finish | Material | Grades |
| Ti-Champagne-Gold | Mirror No.8 | Cold Rolled Stainless Steel | 304 304L 316 316L 201 430 |
| Dimensional Details | |||
| Dimensional Details Grooved / Sharp Bend | |||
| Shape Type & Code | Sizes ( H X W X H ) | Thickness | Length |
U-U1 |
|||
| 10 x 3 x 10
10 x 5 x 10 10 x 8 x 10 |
0.5 mm 0.6 mm 0.8 mm |
2438mm (8 FT) 3048mm (10 FT) |
|
CUSTOMISED SIZE, LENGTHS, COLOURS & SURFACE FINISHES AVAILABLE ON REQUEST
| Appx. Weight Per Piece in Kg's L = 2438 | ||||||||
| Thickness | 6x6 | 8x6 | 10x6 | 12x6 | 16x6 | 20x6 | 25x6 | 30x6 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| Appx. Weight Per Piece in Kg's L = 3048 | ||||||||
| Thickness | 6x6 | 8x6 | 10x6 | 12x6 | 16x6 | 20x6 | 25x6 | 30x6 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
| 0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
