Product Information | |
Category | Flat Tubes |
Material | Cold Rolled Stainless Steel |
Mfg. STD | ASTM A-240 |
Grades | 304, 304L, 316 & 316L |
Tolerances | Outer Dimensions : ± 5% , Wall Thickness : ± 10%, Ovality : ± 5% |
Colour | Ti-Rose Gold |
Surface Finish | Matte |
Process Information | Unfinished Tubes (Raw Material) |
To make decorative Stainless Steel Hairline Finish Flat Tubes, We use high quality Cold Rolled ERW SS tubes from India & neighbouring countries. |
Polishing | These Tubes are Polished on Sophisticated Polishing Machines to give an excellent Ti-Rose Gold Hairline Surface Finish. |
Colouring | Using PVD (Physical Vapour Deposition) Technology, these tubes are kept for sufficient time in the PVD Chamber to get desired Ti-Rose Gold Hairline Finish Round Tubes. |
Protective Covering |
To protect the Tube's Finished Surface while handling & transportation, we use Polythene Bags/Rolls. |
Material Specification | |||
Colour | Surface Finish | Material | Grades |
Ti-Rose Gold | Matte | Cold Rolled Stainless Steel | 304 / 304L 316 & 316L |
Dimensional Details | |||
OD (a X b) | Thickness | Length | |
10 X 20 10 X 30 14 X 25 15 X 30 15 X 38 20 X 40 20 X 50 20 X 60 23 X 38 25 X 38 25 X 80 28 X 46 30 X 50 30 X 60 38 X 62 40 X 60 40 X 80 40 X 110 42 X 75 46 X 100 |
1.5 mm / 2.0 mm | 5000 mm to 6000 mm |
CUSTOMISED SIZE, LENGTHS, COLOURS & SURFACE FINISHES AVAILABLE ON REQUEST
Appx. Weight Per Piece in Kg's L = 2438 | ||||||||
Thickness | 6x6 | 8x6 | 10x6 | 12x6 | 16x6 | 20x6 | 25x6 | 30x6 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
Appx. Weight Per Piece in Kg's L = 3048 | ||||||||
Thickness | 6x6 | 8x6 | 10x6 | 12x6 | 16x6 | 20x6 | 25x6 | 30x6 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
0.6 mm | 14.25 | 17.75 | 0.45 | 4.80 | 0.45 | 4.80 | 4.80 | 4.80 |
